Xpelair VX100T-SP Bathroom Fan - Timer - Rated @ 21l/s

Xpelair VX100T-SP Bathroom Fan

Part Number: 92931AW

The VX100 Axial Extract Fan with Short Spigot (Timer) is a compact 100mm ventilation solution designed for shallow wall or ceiling installations where space is limited. The short spigot design makes it ideal for bathrooms, shower rooms, and en-suites, offering reliable extraction performance in domestic wet areas.

This single-speed axial fan delivers efficient airflow and is powered by a low-energy AC motor with thermal cut-out protection. A lubricated-for-life motor ensures quiet, maintenance-free operation and long-term reliability.

As a Timer model, the VX100T-SP is activated via an external switch—such as a lighting circuit—and continues to run after the switch is turned off. The adjustable overrun timer can be set between 90 seconds and 30 minutes, helping to remove excess moisture and reduce condensation after use.

The fan complies with Building Regulations Part F and Scottish Building Standards, making it a dependable choice for compliant bathroom ventilation.

Key Features

General

- Product Name: VX100 Axial Extract Fan with Short Spigot – Timer

- Product Model Number: VX100T-SP

- Fan Type: Axial extract fan

- Control Type: External switch with adjustable timer overrun

- Timer Function: Yes

- Timer Overrun: Adjustable from 90 seconds to 30 minutes

- Humidistat: No

Performance

- Airflow Performance: 76 m³/h

- Operating Speed: Single speed

Electrical

- Power Consumption: 12W

- Loading / Wattage: 0.012 kW

- Motor Type: AC motor

- Motor Protection: Thermal cut-out

- Motor Bearings: Lubricated for life

Installation

- Spigot Size: 100mm (4")

- Spigot Length: Short spigot (for shallow installations)

- Mounting Options: Wall or ceiling mounted

Construction & Finish

- Colour: White

- Finish: Glossy

- Material: ABS plastic

Ingress Protection

- IP Rating: IPX4

Dimensions & Weight

- Width: 164 mm

- Height: 89 mm

- Depth: 159 mm

- Weight: 0.49 kg

Compliance & Identification

- Compliance: Building Regulations Part F, Scottish Building Standards

- EAN: 5013562929318
